Description

ZLINE 46″ Width Wall Mount Range Hood Insert (18″ Depth), 698-46

OPTIONS & ACCESSORIES

Ductless/Recirculate Option – No
Crown Molding(s) – NA
Certified Outdoor Use – No
Also available in 28″(698-28), 34″(698-34), 40″(698-40)

PRODUCT DESCRIPTION:

The ZLINE 698-46 is a 46-inch professional range hood insert designed to be both elegant and powerful, featuring the industry’s only lifetime warranty motor. This hood is made from 430-grade stainless steel and is a ZLINE classic. Its durable construction, modern design, and lifetime warranty motor – a ZLINE exclusive – guarantee a range hood with a timeless design that will last a lifetime.

This hood contains many unique features, such as:
• Dishwasher-safe stainless steel baffle filters
• Built-in LED lighting
• High performance 4-speed motor with speeds up to 700 CFM

All ZLINE range hoods are ETL Listed and come equipped with everything needed to easily install and use.

ZLINE is the industry leader in range hoods and stands by the quality and longevity of their stainless steel range hoods. The 698-46 ships next business day when in stock.

User ManualPDFInstallation ManualPDF

This ZLINE Professional 36″ 22.5 cu. ft Freestanding French Door Refrigerator, crafted in Lake Tahoe, USA, combines top-tier performance with classic design. This refrigerator is packed with innovative features to enhance your kitchen experience, making it the perfect blend of style and functionality.

• Built-in Ice Maker: Enjoy the convenience of an automatic ice maker that produces up to 4.85 lbs of ice daily, with easy access to up to 1.75 lbs of stored ice.
• Spacious Interior: With a generous 22.5 cu. ft. capacity and two large freezer drawers, you’ll have plenty of space to keep your groceries organized and within reach.
• Counter Depth Design: Achieve a sleek, modern kitchen look with a fridge that fits perfectly flush with your countertops.
• Customizable Temperature Control: Adjust the refrigerator temperature between 34°F to 44°F and freezer settings from -7°F to 7°F, ensuring your food is stored in the ideal environment.
• RapidChill Mode: Need to cool something quickly? Use the RapidChill mode to save time and keep your food fresh.
• Digital ChillControl: Easily manage temperatures and switch between modes—vacation, sabbath, or eco—using the intuitive LED display.
• CrispControl Drawer: Keep fruits and vegetables fresh longer with two adjustable temperature crisper drawers.
• Dual Cooling System: Separate cooling systems for the refrigerator and freezer ensure optimal freshness and prevent odors from mixing.
• Fingerprint-Resistant Finish: Keep your fridge looking spotless with our smudge-proof, fingerprint-resistant stainless steel finish.
• Energy Efficient: ENERGY STAR rated for superior insulation and an energy-reducing cooling system, combining power with savings.

*Assembly Required: This refrigerator and its door handles will ship in multiple boxes and requires assembly upon installation.

• Dimensions: 35.8″ W x 29″ D x 69.9″ H
• Depth With Door Open: 43.2″
• Depth Type: Counter Depth
• Door Style: French Door
• Capacity: Total Capacity – 22.5 cu. ft. // Fridge Capacity – 15.9 cu. ft. // Freezer Capacity – 6.6 cu. ft.
• Number of Fridge Shelves: 4
• Electrical Requirements: 120V/60Hz/15A
• Noise Level: 43 dBA
• Ice Maker: Yes – Internal
• Ice Maker Type: Single Ice Maker
• Ice Amount per Day (lbs.): 4.85 lbs
• Ice Tray Storage: 1.75 lbs
• Water Dispenser: No
• Certifications: UL Listed, ENERGY STAR Certified
• Warranty: 1 year parts and service and 5 year parts on sealed system, including compressor, evaporator coil, condenser coil, filter drier

User Manual
Installation Manual
